Installation/removal
Wiring around the cockpit (junction [A])
2. Connect the electric wire to the E-TUBE port of junction [A].
If necessary, secure the electric wire connecting the switch unit and EW-EN100 to either
the brake hose or brake outer casing, using a cord clip.
Cord clip
Brake hose or brake outer
casing
Y70H98040 (EW-SD50 type)
EW-CL300 (EW-SD300 type)
