Connection and communication with devices
Connection with all SHIMANO STEPS components
Bracket installation type cycle computer
Refer to the figure when connecting.
SM-PCE02
SM-PCE1
Connect to drive unit
Connect to switch unit
With free port
Connect to switch unit
SM-PCE1
SM-PCE02
SM-JC40/SM-JC41
Connect to drive unit
Connect to switch unit
Without free port
