Indirectly-pressurized Supply of Tap Water
V. Pump Wiring Diagram
VI. Installation Diagram
Wiring of
single-phase
pump
Wiring of
three-phase
pump
Capacitor
(Yellow/green)
Subline
Secondary
winding
Main
winding
Common line
(Black/red)
Main line (white)
