ENGLISH

SHINDAIWA OWNER’S/OPERATOR’S MANUAL

B450 BRUSHCUTTER

Part Number 62022-94113 Rev. 5/05

EPA VERSION

Minimize the risk of injury to yourself and others!

Read this manual and familiarize yourself with the

contents. Always wear eye and hearing protection

when operating this unit.

WARNING!

Main Page

Other manuals for Shindaiwa B450

Owner's/Operator's Manual24 pages

Questions and Answers

N
Nicholas VasquezJul 26, 2025
How to fix a Shindaiwa Brush Cutter that won't start?
- C
  cookstevenJul 26, 2025
  If your Shindaiwa Brush Cutter engine won't start, first, ensure the ignition switch is in the “I” (ON) position. If it isn't starting, the spark plug could be the issue. Try cleaning and regapping the plug to 0.024 inch (0.6mm). If the plug is internally damaged or the wrong size, replace it with a Champion CJ8 or equivalent. Also, ensure you're using the correct fuel mixture: clean, fresh unleaded gasoline with an octane rating of 87 or higher, mixed with Shindaiwa Premium 2-cycle mixing oil at a 50:1 ratio. If the plug is wet, crank the engine with it removed, then reinstall it and try restarting. Check the fuel filter and vent, and replace if clogged. If the spark plug is loose, tighten it.
M
mcoleAug 10, 2025
What to do if my Shindaiwa Brush Cutter has low power output?
- J
  John NashAug 10, 2025
  If your Shindaiwa Brush Cutter has low power output, try shortening the trimmer line and cutting at a slower rate to avoid overworking the unit. Ensure you're using the correct fuel ratio: clean, fresh unleaded gasoline with a pump octane of 87 or higher, mixed with Shindaiwa Premium 2-cycle mixing oil at a 50:1 gasoline/oil ratio. Check and clean or replace the air filter if it's clogged. Inspect the spark plug; if it's loose or damaged, tighten or replace it with a Champion CJ8 or equivalent. Repair or replace the fuel line if there is air leakage or it is clogged. Refill with a fresh fuel/oil mixture if there is water in the fuel. Also, check the fuel octane rating and for the presence of alcohol in the fuel and refuel as necessary.

Summary

General Safety Instructions

Work Safely

Brushcutters operate at high speeds and can cause damage or injury if misused. Never allow untrained persons to operate.

Stay Alert

Use Good Judgment

Always wear eye protection, never operate indoors, clear work area, use proper cutting tool, stop if unit vibrates, keep clean.

The Properly Equipped Operator

Wear protective clothing, hearing protection, eye protection, appropriate footwear, and a harness when operating with a blade.

Be Aware of the Working Environment

Bystander Safety

Keep bystanders at least 50 feet away and ensure they wear eye protection. Reduce risk of bystanders being struck by flying debris.

Cutting Attachment Shield

Assembly and Adjustments

Install Mainshaft and Outer Tube

Install the Cutting Attachment Shield

Instructions for attaching the shield extension, securing the shield, and ensuring proper installation of the sub-shield.

Handlebar Assembly

Connecting Throttle Cable Ends

Throttle Control Adjustment

Instructions for centering the throttle cable sleeve, closing the connector, securing with cable ties, and installing the hip protector.

Adjust Throttle Free Play

Procedures for testing throttle control, checking free play clearance, and adjusting it using the cable adjuster and locknut.

Install the Blade

Step-by-step guide for installing the brushcutter blade, including securing the safety clip, holders, and shaft bolt.

Install the Trimmer Head

Instructions for assembling the trimmer head, including removing unused parts and securing Holder A and the trimmer head.

Mixing Fuel

Fuel;Oil Ratio and Types

Specifies using unleaded gasoline and Shindaiwa Premium 2-cycle mixing oil at a 50:1 ratio. Warns against alcohol content and generic oils.

Filling the Fuel Tank

Safety warnings and instructions for refueling, including stopping the engine, allowing it to cool, and avoiding spills.

Starting the Engine

Preparing for Starting

Instructions for setting the throttle control to fast idle and ensuring the ignition switch is ON.

Priming and Choking

Engaging the Starter

How to pull the starter cord slowly until it engages, then rapidly to start the engine.

Starting a Flooded Engine

Stopping the Engine

Adjusting Engine Idle

Shoulder Strap & Harness

Harness Adjustment and Usage

Instructions on adjusting the shoulder strap and harness for comfort and secure operation, especially with a blade.

Checking Unit Condition

Using A Brushcutter Blade

Blade Safety Precautions

Warnings about inspecting the blade, not using damaged blades, and using approved blades.

Blade Cutting Techniques

Proper techniques for moving the blade (right to left), positioning for cuts, and avoiding specific cutting zones.

Blade Thrust and Handlebar

Trimming;Mowing Grass Using A Trimmer Head

Trimmer Head Operation Cautions

Trimmer Head Types and Cutting Procedures

General Maintenance

Safety Precautions for Maintenance

Warnings about stopping the engine, disconnecting the spark plug wire, and avoiding non-standard parts.

Blade Maintenance and Safety

Daily Maintenance Checklist

10-hour Maintenance: Air Filter

Maintenance Schedule

10;15-Hour Maintenance: Spark Plug

50-hour Maintenance: Cylinder Cover and Gearcase Grease

50-hour Maintenance: Fuel Filter

Spark Arrester Screen Maintenance

Blade Sharpening

Blade Sharpening Safety

Warning to sharpen cutting teeth only and not alter the blade contour.

Sharpening Shindaiwa Tornado Blade

Sharpening Multiple-tooth Circular Blade

Troubleshooting Guide

Engine Does Not Start Troubleshooting

Guide to diagnose and remedy issues when the engine fails to start.

Low Power Output Troubleshooting

Additional Problems: Poor Acceleration and Engine Stops Abruptly

Additional Problems: Cutting Attachment Rotation and Vibration

Shindaiwa B450 Specifications

General

Engine Displacement	41.5 cc
Engine Type	2-stroke
Shaft Type	Straight
Starter System	Recoil
Fuel Capacity	0.95 L
Fuel Tank Capacity	33.8 fl. oz.
Cutting Width	430 mm
