30(64)
2.4.6 Electrical Components List (SMD-500H~1500H)
Table 2-3：Electrical Components List (SMD-500H)
No. Symbol
Name Specifications Part No.
1 Q1 Main switch 16A 690V 3P YE10200300000
2 Q2 Circuit breaker* 20A 400V 3P YE40602000100
3 - Circuit breakers S9 YE40000900000
4 K1 Contactor* 230V 50/60Hz YE00301000000
5 K2 Contactor* 230V 50/60Hz YE00301000000
6 K3 Contactor* 230V 50/60Hz YE00310000000
7 K4 Middle relay* 230VAC 50/60Hz YE03270700000
8 K5 Timer 230VAC 50/60Hz YE86300300000
9 K6 Dew-point meter 100~240VAC 50/60Hz YE85122000100
10 F1 Overload relay* 2~3.2A YE01023200000
11 F2 Overload relay* 1~1.6A YE01011600000
12 F11 Fuse** 2A 250VAC YE41001000000
13 T Transformer* IN=400V OUT=230V 500mA YE70040000300
14 S1 Micro switch* 10A YE14511200000
15 S2 Thermocouple - BE90300000050
16 S3 Overheat protector* 250V 5(4)A YE21503000100
17 S4 Dew-point transducer*
18 PCB-01 PCB* STC43/44 YE80001500000
19 PCB-02 PCB* SFD-102 YE80010200000
20 FM FAN* 220-240~50/60Hz 0.14A YM60121200400
21 H1 Buzzer 24VDC YE84002700000
22 X1 Terminal board - YE61250000000
23 - Terminal board - YE61253500000
24 X2 Terminal board - YE61250000000
25 - Terminal board - YE61253500000
26 X3 Terminal board - YE61250000000
27 - Terminal board - YE61253500000
28 X4 Terminal board - YE61250000000
29 - Terminal board - YE61253500000
30 X5 Terminal board - YE61250000000
31 - Terminal board - YE61253500000
32 M1 Drying blower* 400V 50Hz 0.75kW YM30075000100
33 M2 Regen. blower* 400V 50Hz 0.4kW BM30020500050
34 M3 Motor* 0.006kW YM50616400100
35 EH1 Heater** 400V 50Hz 5kW BH70200400050
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
