Shining 3D Aoralscan 3 - Hardware Specification; Specifications; Environmental Requirements

Aoralscan 3_Manual_V1.0.0.30 - 52 -
9. Hardware Specification
Specifications
Type name
Intraoral Scanner
Model name
Aoralscan 3
Scanner
Scan field
Standard scanner head: 16 mm × 12 mm × 17 mm
Small scanner head: 12 mm × 9 mm × 17 mm
Scan theory
Non-contact scanner with the structured light
Dimension (L × W × H)
281 mm × 33 mm × 46 mm
Weight
240 ± 10 g (without cables)
Output
STL, OBJ, PLY
Connector
USB 3.0
Power
Input: 12V DC/3 A
Pedestal
Dimension (L × W × H)
146 mm × 82 mm × 86 mm
Weight
400 ± 10 g
Product life
8 years
Environmental Requirements
Operating and storage requirements
⚫ Operating temperature: 10°C –40°C
⚫ Storage/Transport temperature: -25°C–60°C
⚫ Operating altitude: < 3000 M
⚫ Storage/Transport/Relative humidity: 30%–75%
⚫ MTBF: 10,000 hours (except DMD/LED)
⚫ Air pressure: 86 kPa–106 kPa
