4. INTERCONNECTION VM-5S
-10-
• Be sure to observe the following cautions at the time of interconnection.
Note No.
in drawing
Caution
1)
To insulate the connector, cover it with the supplied shrink tube (insulating
sleeve) or insulating tape.
Take measures to prevent oil or water from entering the insulating sleeve or
tape.
Allowable bending radius
Without armor : 30 mm (1.18 in REF.)
With armor : 50 mm (1.97 in REF.)
Allowable tension : 98.1N (10 kgf REF.)
2)
Connect the shielded wires to the COM terminal.
Keep the unshielded portion of cables at connecting parts as short as possible.
(less than 100mm recommended.)
3)
Use a 3-core shielded cable with AWG No. 14 to No. 18 gage stranded
conductors for wiring between the VK driver and the monitor.
Do not wire the cables together in high tension ducts.
• Make sure to turn the power off before wiring work to prevent accidents due to
electric shock.
Warning
Mandantory
