7. PARAMETER SETTING VM-5S
-48-
Fig. 7-6-2
Fig.7-6-3
Trigger Level
Setting Voltage
Hysteresis
0V
5V
Monitor Output
Pulse Output
-20V
0V
t
t
Trigger Level
Setting Voltage
Hysteresis
0V
5V
Monitor Output
Pulse Output
-20V
0V
t
t
