Shott BP-50HS-A - User Manual

Questions and Answers

M
martin23Sep 18, 2025
What does error message EE 9 on my Shott Heat Pump mean?
- B
  Brandon MillerSep 18, 2025
  If your Shott Heat Pump is showing error message EE 9, it could indicate several issues: the high or low pressure sensor might be incorrectly connected or defective, so check the connections and replace if necessary. The pool temperature or ambient temperature might be too high, so wait until they drop. The capillary circuit could be clogged, requiring replacement. Also, it's possible that manual defrost was started without frost on the plate heat exchanger; in this case, turn the unit off, then on, and start the pump.
N
ncardenasAug 25, 2025
What to do if my Shott Heat Pump displays error message EE b?
- S
  Seth GarciaAug 25, 2025
  If your Shott Heat Pump shows error message EE b, it indicates insufficient water flow. Increase the water flow in the hydraulic circuit that supplies the heat pump and restart after 2 minutes. Alternatively, the flow sensor might be incorrectly connected or defective, so check the connections and replace the sensor if necessary.
H
Hannah HensonAug 25, 2025
What to do if my Shott BP-50HS-A Heat Pump does not turn on?
- M
  Mandy FlemingAug 26, 2025
  If your Shott Heat Pump does not turn on, ensure that you have followed all instructions. Additionally, check the mains connection line protection device fuse and the contact switch; reset the switch or replace the fuse if necessary.
J
Juan ValdezAug 26, 2025
What does it mean if my Shott BP-50HS-A displays error message EE 6 and doesn't work?
- W
  William RoblesAug 27, 2025
  If your Shott Heat Pump displays error message EE 6 and does not work, it could be due to several reasons. The compressor temperature might be too high, so wait for it to drop. Alternatively, there could be a refrigerant circuit leak, in which case you should check for leaks with a leak detector and replace any defective parts. Finally, the capillary circuit might be clogged, requiring you to replace it.
P
Paul NelsonSep 18, 2025
What does error message EE c on my Shott BP-50HS-A Heat Pump mean?
- D
  david68Sep 18, 2025
  If your Shott Heat Pump displays error message EE c, it indicates that the ambient temperature is under -15 [°C] or lower than the minimum working temperature. Wait until the ambient temperature rises to start the heat pump or set the minimum working temperature again.
M
Mark SmithSep 23, 2025
What to do if my Shott BP-50HS-A Heat Pump does not work and error message EE 7 is displayed?
- Y
  Yvette AllenSep 23, 2025
  If your Shott Heat Pump displays error message EE 7 and isn't working, it indicates current dispersion. Replace the defective component, such as the compressor, fan, four-way valve, or electronic board.
C
Courtney RodriguezSep 9, 2025
What to do if my Shott BP-50HS-A Heat Pump does not start?
- T
  Tami BrownSep 9, 2025
  If your Shott Heat Pump doesn't start, first ensure that the 3 minutes required for pump start have elapsed. If the pool temperature is at or above the set temperature, the pump will only start when the pool temperature drops below the set temperature. Finally, confirm that the pump operating mode is set to the required mode.
T
Thomas MullinsSep 10, 2025
What to do if my Shott BP-50HS-A does not work and error message EE 1 is displayed?
- D
  davidhallSep 10, 2025
  If your Shott Heat Pump displays error message EE 1 and isn't working, the pool temperature sensor may be incorrectly connected or defective. Check the sensor resistance value and replace it if necessary. You can also replace the control board.
C
Carolyn Scott DDSSep 3, 2025
What does it mean if my Shott BP-50HS-A Heat Pump displays error message EE 3?
- S
  Scott GriffinSep 3, 2025
  If your Shott Heat Pump is running and displays error message EE 3, it indicates that the compressor temperature sensor is incorrectly connected or defective. Check the sensor resistance value and replace it if necessary.
L
laurataylorSep 1, 2025
What to do if my Shott BP-50HS-A displays error message EE c?
- T
  Tonya JordanSep 1, 2025
  If your Shott Heat Pump displays error message EE c, it means the ambient temperature is under -15 [°C]. Wait until the ambient temperature rises to start the heat pump.

Summary

General Warnings and Information

CE Declaration

Formal statement of compliance with EU directives for the machinery.

Warranty

General Conditions

Details the warranty period, conditions, and exclusions for the product.

Special Conditions

Specific warranty applicability and validation requirements within EU member countries.

Restrictions

Limitations on warranty coverage, such as consumer sales and misuse.

Symbol Key

Safety Regulations and Energy Savings

Safety Regulations for Heated Pools

Essential safety guidelines for using heated swimming pools to prevent accidents.

Energy Savings

Tips and recommendations for optimizing heat pump energy consumption and performance.

General Information and Definitions

Product Presentation

Product Scope

Defines the intended use and application of the SERIES BP heat pumps.

Heat Pump Composition

Technical Specifications

Installation

Inspection and Handling

Procedures for checking the unit upon arrival and safe methods for handling.

Positioning Requirements

Guidance on selecting an appropriate location and mounting the heat pump.

Clearance, Noise, and Disposal

Hydraulic Connections

Electrical Connections

Mains Connection

Socket Installation

Steps for installing the mains connection socket, ensuring correct IP grade and grounding.

Cord Replacement

Procedure for safely replacing the heat pump's mains connection cord.

Commissioning and Preliminary Checks

Operations and Use

Control Panel Overview

Explanation of the heat pump control panel buttons, display, and basic operations like turning on/off.

Heat Pump Operations

Starting, Mode, and Temperature Settings

Procedures for starting the unit, selecting operating modes, and adjusting set temperatures.

Working Temperature and Automatic Settings

Configuration of minimum working temps, automatic start, and standby modes.

Defrost, Key Lock, and Sensor Display

Functions for manual defrost, locking controls, and viewing sensor temperatures on the display.

Functional Parameter Settings

Defrost and Protection Parameters

Configuration options for defrost cycles and compressor protection settings.

Temperature Range Parameters

Adjusting pool temperature regulation, defrost start/stop temperatures.

Defrost Timing and Compressor Parameters

Setting defrost repetition time, duration, and compressor temperature limits.

Restart, Mode, and Deviation Parameters

Configuring automatic restart, operating mode, and temperature deviation settings.

Control Mode & Manometer Use

Selecting control mode and understanding manometer readings for pressure monitoring.

Control and Safety Devices

Temperature and Flow Sensors

Details on ambient, pool, flow, compressor, and plate heat exchanger sensors.

High Pressure Sensor Function

Explains the role of the high pressure sensor in protecting the compressor.

Low Pressure Sensor Function

Explains the role of the low pressure sensor in protecting the compressor.

Sensor Resistance Values

Temperature Sensor Resistance Values

Table providing resistance values for temperature sensors at various temperatures.

Compressor Temperature Sensor Resistance Values

Table providing resistance values for the compressor temperature sensor.

Maintenance and Troubleshooting

Routine Maintenance Checks

Tasks for users and specialized technicians for regular checks and upkeep.

Winter Protection and Spring Commissioning

Procedures for protecting the unit during winter and recommissioning in spring.

Troubleshooting Common Problems

Identifies common issues like no start, no heating, or frost, and provides solutions.

Troubleshooting Error Messages

Guides for resolving specific error codes displayed by the heat pump.

Spare Parts

Spare Parts for BP-xxHS-A Models

Lists and illustrates spare parts for the BP-xxHS-A model, with part numbers.

Spare Parts for BP-xxWS-B Models

Lists and illustrates spare parts for the BP-xxWS-B model, with part numbers.

Special Notes on Part Replacement

Specific instructions for replacing key components like manometer, sensors, filter, and capillary.

Shott BP-50HS-A Specifications
