B P - 3 5 W S - B
B P - 5 0 W S - B
B P - 5 0 H S - A
B P - 8 5 H S - A
B P - 1 0 0 H S - A
Installation manual

Table of Contents

Questions and Answers

  • J
    Jacqueline MartinezSep 17, 2025
    What does error message EE 9 on my Shott BP-85HS-A mean?
    • E
      Edward FergusonSep 18, 2025
      If your Shott Heat Pump is showing error message EE 9, it could indicate several issues: the high or low pressure sensor might be incorrectly connected or defective, so check the connections and replace if necessary. The pool temperature or ambient temperature might be too high, so wait until they drop. The capillary circuit could be clogged, requiring replacement. Also, it's possible that manual defrost was started without frost on the plate heat exchanger; in this case, turn the unit off, then on, and start the pump.
  • M
    Mary VelasquezAug 25, 2025
    What to do if my Shott BP-85HS-A Heat Pump displays error message EE b?
    • W
      wesleykiddAug 25, 2025
      If your Shott Heat Pump shows error message EE b, it indicates insufficient water flow. Increase the water flow in the hydraulic circuit that supplies the heat pump and restart after 2 minutes. Alternatively, the flow sensor might be incorrectly connected or defective, so check the connections and replace the sensor if necessary.
  • C
    Cassie LarsonAug 25, 2025
    What to do if my Shott Heat Pump does not turn on?
    • J
      James AguirreAug 26, 2025
      If your Shott Heat Pump does not turn on, ensure that you have followed all instructions. Additionally, check the mains connection line protection device fuse and the contact switch; reset the switch or replace the fuse if necessary.
  • R
    ryan18Aug 26, 2025
    What does it mean if my Shott Heat Pump displays error message EE 6 and doesn't work?
    • L
      Laura BurkeAug 27, 2025
      If your Shott Heat Pump displays error message EE 6 and does not work, it could be due to several reasons. The compressor temperature might be too high, so wait for it to drop. Alternatively, there could be a refrigerant circuit leak, in which case you should check for leaks with a leak detector and replace any defective parts. Finally, the capillary circuit might be clogged, requiring you to replace it.
  • P
    Pamela PenaSep 18, 2025
    What does error message EE c on my Shott BP-85HS-A mean?
    • T
      Tammy BurnettSep 18, 2025
      If your Shott Heat Pump displays error message EE c, it indicates that the ambient temperature is under -15 [°C] or lower than the minimum working temperature. Wait until the ambient temperature rises to start the heat pump or set the minimum working temperature again.
  • R
    Robert BlairSep 23, 2025
    What to do if my Shott Heat Pump does not work and error message EE 7 is displayed?
    • E
      ericperezSep 23, 2025
      If your Shott Heat Pump displays error message EE 7 and isn't working, it indicates current dispersion. Replace the defective component, such as the compressor, fan, four-way valve, or electronic board.
  • M
    Michelle PrattSep 9, 2025
    What to do if my Shott Heat Pump does not start?
    • J
      Jake AndrewsSep 9, 2025
      If your Shott Heat Pump doesn't start, first ensure that the 3 minutes required for pump start have elapsed. If the pool temperature is at or above the set temperature, the pump will only start when the pool temperature drops below the set temperature. Finally, confirm that the pump operating mode is set to the required mode.
  • J
    Joseph HowardSep 10, 2025
    What to do if my Shott BP-85HS-A does not work and error message EE 1 is displayed?
    • T
      Tyler WeaverSep 10, 2025
      If your Shott Heat Pump displays error message EE 1 and isn't working, the pool temperature sensor may be incorrectly connected or defective. Check the sensor resistance value and replace it if necessary. You can also replace the control board.
  • P
    Pamela MillerSep 3, 2025
    What does it mean if my Shott BP-85HS-A displays error message EE 3?
    • G
      Gary GonzalezSep 3, 2025
      If your Shott Heat Pump is running and displays error message EE 3, it indicates that the compressor temperature sensor is incorrectly connected or defective. Check the sensor resistance value and replace it if necessary.
  • C
    Chad WoodSep 1, 2025
    What to do if my Shott BP-85HS-A displays error message EE c?
    • M
      Matthew JohnsonSep 1, 2025
      If your Shott Heat Pump displays error message EE c, it means the ambient temperature is under -15 [°C]. Wait until the ambient temperature rises to start the heat pump.

Summary

General Warnings and Information

CE Declaration

Declaration of conformity to EU directives and standards for heat pumps.

Warranty

Covers general, special, and restricted conditions of the product warranty.

Safety Regulations for Heated Pools

Crucial safety guidelines for using heated pools, including temperature limits.

Energy Savings

Recommendations for optimizing energy consumption and savings for the heat pump.

Product Presentation

Overview of the product scope, composition, and definitions.

Technical Specifications

Installation

Inspection, Handling, and Positioning

Steps for inspecting, handling, and positioning the heat pump correctly.

Clearance, Noise, and Disposal

Guidelines for necessary clearance, noise reduction, and proper disposal.

Hydraulic Connections

Instructions for connecting water circuits, including warnings and layout.

Electrical Connections

Essential steps for making safe and correct electrical connections to the heat pump.

Socket Installation and Cord Replacement

Procedures for installing mains sockets and replacing the power cord.

Commissioning and Preliminary Checks

Final checks and precautions before initial start-up and commissioning.

Operations and Use

Control Panel Operation

Guide to using the control panel: turning on/off, standby, starting, and mode selection.

Starting and Temperature Settings

Steps for starting the heat pump and regulating temperature.

Automatic Operation Settings

Configuration of automatic start and standby modes for convenience.

Special Functions and Sensor Display

Using manual defrost, key lock, and displaying sensor temperatures.

Functional Parameter Settings

Accessing and modifying advanced functional parameters for heat pump operation.

Parameter Settings Details

Specific settings for pool temperature, defrost start, and stop temperatures.

More Parameter Settings

Details on defrost repetition time, duration, and compressor protection temperature.

Advanced Parameter Adjustments

Settings for automatic restart, operating mode, and temperature deviation.

Control Mode and Manometer Use

Selecting control modes and using the pressure manometer.

Control and Safety Devices

Control Devices

Information on ambient, pool temperature, and flow sensors.

Safety Devices

Details on compressor, heat exchanger, and pressure sensors for safety.

Low Pressure Sensor

Function and trigger pressure of the low pressure sensor.

Temperature Sensor Resistance Values

Tables of resistance values for temperature sensors.

Compressor Sensor Resistance Values

Tables of resistance values for the compressor temperature sensor.

Maintenance and Troubleshooting

Routine Controls and Seasonal Procedures

User checks, technician controls, winter protection, and spring commissioning.

Troubleshooting

Guide to solving common heat pump issues and error messages.

Spare Parts and Replacement

Special Notes on Part Replacement

Special notes for replacing specific parts like manometer, sensors, filter, and capillary.

Frost on Radiator

Procedure for checking and addressing frost on the radiator.
