SHOWTEC LED Light Bar 8 - DMX Channel Functions Part 2; 7 DMX Channels (d-P6)

21
2 DMX Channels (d-P5)
Channel 1 – Color
0-7
No Function
8-15
Red
16-23
Yellow
24-31
Green
32-39
Cyan
40-47
Blue
48-55
Purple
56-63
White
64-71
Program 1
72-79
Program 2
80-87
Program 3
88-95
Program 4
96-103
Program 5
104-111
Program 6
112-119
Program 7
120-127
Program 8
128-135
Program 9
136-143
Program 10
144-151
Program 11
152-159
Program 12
160-167
Program 13
168-175
Program 14
176-183
Program 15
184-191
Program 16
192-199
Program 17
200-207
Program 18
208-215
Program 19
216-223
Program 20
224-231
Program 21
232-255
Sound Mode
Channel 2 – No Function (when Channel 1 is set between 1-7 )
0-255
From slow to fast
Channel 2 – Speed (Channel 1 must be set between 8-231 )
0-255
From slow to fast
Channel 2 – Sensitivity (Channel 1 must be set between 232-255 )
0-255
From low to high sensitivity
