7 DMX Channels (d-P6)
Channel 1 – Red
0-255
Gradual adjustment Red from 0 – 100%
Channel 2 – Green
0-255
Gradual adjustment Green from 0 – 100%
Channel 3 – Blue
0-255
Gradual adjustment Blue from 0 – 100%
Channel 4 – Color
0-7
No Function
8-15
Red
16-23
Yellow
24-31
Green
32-39
Cyan
40-47
Blue
48-55
Purple
56-63
White
64-71
Program 1
72-79
Program 2
80-87
Program 3
88-95
Program 4
96-103
Program 5
104-111
Program 6
112-119
Program 7
120-127
Program 8
128-135
Program 9
136-143
Program 10
144-151
Program 11
152-159
Program 12
160-167
Program 13
168-175
Program 14
176-183
Program 15
184-191
Program 16
192-199
Program 17
200-207
Program 18
208-215
Program 19
216-223
Program 20
224-231
Program 21
232-255
Sound Mode
Channel 5 – No Function (when Channel 4 is set between 1-7 )
0-255
From slow to fast
Channel 5 – Speed (Channel 4 must be set between 8-231 )
0-255
From slow to fast
Channel 5 – Sensitivity (Channel 4 must be set between 232-255 )
0-255
From low to high sensitivity
Channel 6 – No Function when Channel 4 is set between 1-7 or 232-255 )
0-255
From slow to fast
Channel 6 – Strobe (Channel 4 must be set between 8-231 )
0-255
Strobe effect from slow to fast
Channel 7 – Master Dimmer
0-255
Dimmer, from closed to open (0-100%)
