Showven Sparkular - Technical Specifications; Operation Panel Overview; LED Display Area; Control Button Area

▲Technical Specifications
\ MODEL: BT01/BT02
\ DIMENSION: 200×218×305mm
\ WEIGHT: 8.5kg
\ VOLTAGE: 220V(BT01)/110V(BT02), 50/60Hz
\ WORK POWER: 500W
\ EFFECT HEIGHT: 1.5-5m adjustable
\ INTERFACE: 3-pin XLR, POWER IN/OUT
\ CONTROL: DMX 2 channels
▲Operation Panel
1. LED display area:
READY DMX FAULT HEAT
READY: Flash means machine is preparing, LED keeps on means ready to operate
DMX: Flash means DMX signal is connected, light OFF means there is no DMX signal
FAULT: Light ON when error occurs
HEAT: Light ON when system is heating up
2. Control button area:
MENU DOWN UP ENTER
MENU: switch through setup menu
DOWN: parameter down
UP: parameter up
ENTER: confirm and save parameters
3. Interface and Plugging Area
T6.3A
250V
POWER IN: power in
POWER OUT: power out
DMX IN: DMX Communication Signal Input
DMX OUT: DMX Communication Signal Output
