Shure Incorporated
16/103
Directional Antennas
The access point contains multiple directional antennas to provide steady, reliable wireless communication with the micro
phones. It sends and receives the RF signal in a cardioid pattern with the greatest sensitivity toward the face of the device. Al
ways aim this side toward the microphone coverage area.
Cardioid RF Pattern
Networked Charger (NCS)
The MXW networked charging station enables battery charging and channel linking from a single location. When a charger is
associated to a group, its channel slots are mapped to access point audio channels. Microphones can then be placed in the
slots to Link to these channels.
Any microphone can recharge in any NCS, regardless of Group association or network connection.
Caution: When the Link button on an associated charger is pressed, all microphones in the charger are mapped to channels
on an access point. This overrides any previously Linked microphones on those channels.
Model Variations
MXWNCS8
Accepts eight boundary, bodypack, or handheld microphones
or four gooseneck bases
MXWNCS4
Accepts four boundary, bodypack, or handheld microphones
or two gooseneck bases
MXWNCS2
Accepts two boundary, bodypack, or handheld microphones.
MXW8 Gooseneck bases are not supported on this charger
