Shure microphone system User Manual

Replacement Parts
Technical Specifications
Audio Input Level –10 dBV maximum at “mic” gain position
+10 dBV maximum at 0dB gain position
+20 dBV maximum at –10dB gain position
Gain Adjustment Range 30 dB
Input Impedance 1mΩ
RF Transmitter Output 10 mW typical (dependent on applicable country regulations)
Dimensions 110 mm H x 64 mm W x 21 mm D (4.3 x 2.5 x 0.8 in.)
Weight 75 grams (2.6 oz.) without battery
Housing Molded ABS
Power Requirements One 9V alkaline or rechargeable battery
Battery Life >8 hours (alkaline)
Working Range 75m (250 ft.) Note: actual range depends on RF signal absorption, reflection,
and interference.
Audio Channel Response Minimum: 45 Hz.
Maximum: 15 kHz (overall system channel depends on
microphone element).
Total Harmonic Distortion 0.5%, typical
Ref. +/– 33 kHz deviation, 1 kHz tone
Dynamic Range >100 dB A-weighted, typical
Operating Temperature
Range
–18°C (0°F) to +57°C (+135°F)
Note: battery characteristics may limit this range
Transmitter Audio Polarity Positive pressure on microphone diaphragm (or positive voltage to tip of
WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3
of low impedance output) and the tip of the high impedance 1/4-inch output.
Audio Input Level +2 dBV maximum at –10dB position
–8 dBV maximum at 0dB position
Gain Adjustment Range 10dB
RF Transmitter Output 10 mW typical (dependent on applicable country regulations)
Dimensions 223.52 L x 53.34 Dia. (8.8 in. x 2.10 in.)
Weight 218 grams (7.7 oz.) without battery
Housing Molded ABS handle and battery cup
Power Requirements One 9V alkaline or rechargeable battery
Battery Life >8 hours (alkaline)
System
PG1 Bodypack Transmitter
PG2 Handheld Transmitter
System Components
All Systems
PG4 or PG88 Receiver
Internal Diversity Antenna System
One 9 volt battery AC Power supply User guide
Vocalist System
Microphone Head PG2 handheld transmitter Microphone clip
Instrument System
PG1 bodypack
transmitter
4-pin mini connector (TA4F) to
1/4” connector cable
Lavalier and Headworn System
PG1 bodypack
transmitter
Microphone (choice of PG185, PG30)
All Systems Microphone Stand Adapter (PGX2) WA371
System-Specific AC Adapter (120 VAC, 60 Hz) PS20
AC Adapter (230 VAC, 50/60 Hz, Europlug) PS20E
AC Adapter (230 VAC, 50/60 Hz, UK) PS20UK
AC Adapter (100 VAC, 50/60 Hz) PS20J
AC Adapter (220 VAC, 50 Hz, China) PS20CHN
AC Adapter (230 VAC, 50 Hz,, Australia) PS20AZ
AC Adapter (220 VAC, 60 Hz, Korea PS20K
PG58 Head with Grille RPW108
Belt Clip 44A8035
Optional Universal Rack Tray URT
4-pin mini connector (TA4F) to 1/4”
connector cable
WA302
