Mounting Instructions
The MV7X microphone comes equipped with a 5/8"-27 threaded mount, the thread size most commonly found on microphone
stands. This mount can be used with a microphone stand or hung from a boom.
Note: Be very careful not to unloosen the screws all the way.
To easily flip the microphone orientation, loosen the screws and rotate 180 degrees.
Windscreen
The windscreen offers maximum protection from plosives and creates a warmer, more intimate sound for speech applications,
like podcasting and gaming.
Specifications
Transducer Type
Dynamic (moving coil)
Polar Pattern
Unidirectional (Cardioid)
Output Impedance
252Ω
Frequency Response
20Hzto20,000Hz
Sensitivity
(@ 1 kHz, open circuit voltage)
-55dBV/Pa[1](1.78mV)

Shure MV7X Specifications

General

Transducer Type	Dynamic
Polar Pattern	Cardioid
Connector	XLR
Frequency Response	50 Hz to 16 kHz
Weight	0.55 kg
Output Impedance	252 ohms
Sensitivity	-55 dBV/Pa at 1 kHz
