Page 16
Outputs – Query Settings
Mute
Note: <VA> equals 00h when the output is unmuted and equals 7Fh when the output is muted.
Output 1: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 46h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 46h <VA> 00h F7h
Output 2: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 47h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 47h <VA> 00h F7h
Output 3: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 48h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 48h <VA> 00h F7h
Output 4: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 49h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 49h <VA> 00h F7h
Output 5: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 4Ah F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 4Ah <VA> 00h F7h
Output 6: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 4Bh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 4Bh <VA> 00h F7h
Output 7: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 4Ch F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 4Ch <VA> 00h F7h
Output 8: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 4Dh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 4Dh <VA> 00h F7h
Polarity
Note: <VA> equals 00h when the output is (+) polarity and equals 01h when the output is (-) polarity.
Output 1: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 4Eh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 4Eh <VA> 00h F7h
Output 2: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 4Fh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 4Fh <VA> 00h F7h
Output 3: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 50h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 50h <VA> 00h F7h
Output 4: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 51h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 51h <VA> 00h F7h
Output 5: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 52h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 52h <VA> 00h F7h
Output 6: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 53h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 53h <VA> 00h F7h
Output 7: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 54h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 54h <VA> 00h F7h
Output 8: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 55h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 55h <VA> 00h F7h
+4/-10 scaling
Note: <VA> equals 00h when the output is +4 dBu scaling and equals 01h when the output is –10 dBV scaling.
Output 1: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 56h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 56h <VA> 00h F7h
Output 2: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 57h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 57h <VA> 00h F7h
Output 3: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 58h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 58h <VA> 00h F7h
Output 4: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 59h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 59h <VA> 00h F7h
