Page 7
Force polarity (+)
Output 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 4Eh 00h F7h
Output 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 4Fh 00h F7h
Output 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 50h 00h F7h
Output 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 51h 00h F7h
Output 5: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 52h 00h F7h
Output 6: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 53h 00h F7h
Output 7: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 55h 00h F7h
Output 8: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 55h 00h F7h
Force polarity (-)
Output 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 4Eh 7Fh F7h
Output 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 4Fh 7Fh F7h
Output 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 50h 7Fh F7h
Output 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 51h 7Fh F7h
Output 5: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 52h 7Fh F7h
Output 6: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 53h 7Fh F7h
Output 7: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 55h 7Fh F7h
Output 8: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 55h 7Fh F7h
+4/-10 scaling
Toggle scaling
Output 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 56h 00h F7h
Output 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 57h 00h F7h
Output 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 58h 00h F7h
Output 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 59h 00h F7h
Output 5: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 5Ah 00h F7h
Output 6: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 5Bh 00h F7h
Output 7: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 5Ch 00h F7h
Output 8: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 03h 5Dh 00h F7h
Force +4 dBu scaling
Output 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 56h 00h F7h
Output 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 57h 00h F7h
Output 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 58h 00h F7h
Output 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 59h 00h F7h
Output 5: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Ah 00h F7h
Output 6: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Bh 00h F7h
Output 7: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Ch 00h F7h
Output 8: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Dh 00h F7h
Force –10 dBV scaling
Output 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 56h 7Fh F7h
Output 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 57h 7Fh F7h
Output 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 58h 7Fh F7h
Output 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 59h 7Fh F7h
Output 5: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Ah 7Fh F7h
Output 6: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Bh 7Fh F7h
Output 7: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Ch 7Fh F7h
Output 8: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 03h 5Dh 7Fh F7h
