Shure P4800 - Input and Output Control

Page 4
CHANGE SETTINGS ON P4800
Note: <Device ID> is a hexadecimal number ranging from 00h to 0Fh. This number should match the DIP switch setting
on the back of the P4800. Once a command is sent, the P4800 will echo the command and then send a return string to
acknowledge the change. The return strings can be seen in the Query section of this white paper.
Inputs – Change Setting
Mute
Toggle Mute
Input 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 04h 00h F7h
Input 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 05h 00h F7h
Input 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 06h 00h F7h
Input 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 07h 00h F7h
Force Mute
Input 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 04h 7Fh F7h
Input 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 05h 7Fh F7h
Input 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 06h 7Fh F7h
Input 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 07h 7Fh F7h
Force Unmute
Input 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 04h 00h F7h
Input 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 05h 00h F7h
Input 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 06h 00h F7h
Input 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 07h 00h F7h
Polarity
Toggle Polarity
Input 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 08h 00h F7h
Input 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 09h 00h F7h
Input 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 0Ah 00h F7h
Input 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 06h 00h 0Bh 00h F7h
Force Polarity (+)
Input 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 08h 00h F7h
Input 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 09h 00h F7h
Input 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 0Ah 00h F7h
Input 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 0Bh 00h F7h
Force Polarity (-)
Input 1: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 08h 7Fh F7h
Input 2: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 09h 7Fh F7h
Input 3: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 0Ah 7Fh F7h
Input 4: F0h 00h 01h 00h <Device ID> 0Ah 69h 01h 00h 0Bh 7Fh F7h
