Shure P4800 - Output Pad (-20 Db); Volume Setting

Page 17
Output 5: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 5Ah F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 5Ah <VA> 00h F7h
Output 6: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 5Bh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 5Bh <VA> 00h F7h
Output 7: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 5Ch F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 5Ch <VA> 00h F7h
Output 8: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 5Dh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 5Dh <VA> 00h F7h
Output Pad (-20 dB)
Note: <VA> equals 00h when the output pad is not engaged and equals 01h when the output pad is engaged.
Output 1: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 5Eh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 5Eh <VA> 00h F7h
Output 2: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 5Fh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 5Fh <VA> 00h F7h
Output 3: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 60h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 60h <VA> 00h F7h
Output 4: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 61h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 61h <VA> 00h F7h
Output 5: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 62h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 62h <VA> 00h F7h
Output 6: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 63h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 63h <VA> 00h F7h
Output 7: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 64h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 64h <VA> 00h F7h
Output 8: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 65h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 65h <VA> 00h F7h
Volume setting
Note: <VA> equals an integer from –60 to +60. Divide <VA> by 2 to get to a dB scale.
Output 1: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 3Eh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 3Eh <VA> 00h F7h
Output 2: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 3Fh F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 3Fh <VA> 00h F7h
Output 3: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 40h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 40h <VA> 00h F7h
Output 4: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 41h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 41h <VA> 00h F7h
Output 5: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 42h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 42h <VA> 00h F7h
Output 6: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 43h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 43h <VA> 00h F7h
Output 7: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 44h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 44h <VA> 00h F7h
Output 8: Query command: F0h 00h 01h 00h <Device ID> 0Ah 70h 03h 45h F7h
Return string: F0h 00h 01h 00h <Device ID + 10h> 0Ah 00h 03h 45h <VA> 00h F7h
