Shure PG4 - Frequency Tables

21
25A1104 (Rev.1)
FREQUENCY TABLES
H7 536 - 548 K7 590 - 602 M7 662-674 M10 674-686 P11 702-714 Q11 740-752
CH Freq CH Freq CH Freq CH Freq CH Freq CH Freq
1 536.075 1 590.075 1 662.075 1 674.025 1 702.075 1 740.125
2 547.925 2 601.925 2 673.925 2 677.900 2 703.275 2 741.325
3 537.275 3 591.275 3 663.275 3 682.775 3 706.025 3 744.075
4 546.725 4 600.725 4 672.725 4 684.700 4 707.925 4 745.975
5 540.025 5 594.025 5 666.025 5* 685.900 A 708.075 A 746.025
6 543.975 6 597.975 6 669.975 6 674.225 b 709.975 b 747.925
7 541.925 7 595.925 7 667.925 7 676.500 C 712.725 C 750.675
8 542.075 8 596.075 8 668.075 8 680.025 d 713.925 d 751.875
9 547.175 9 601.175 9 673.175 9 684.500
0 536.825 0 590.825 0 662.825 0** 685.700
R10 800-812 R11 770-782 R12 794-806 JB 806-810 T10 854 - 865 FCC ISM 902 - 928
CH Freq CH Freq CH Freq CH Freq CH Freq CH Freq
1 802.525 1 770.075 1 794.075 1 806.125 1 855.275 1 902.000
2 800.525 2 771.275 2 795.275 2 806.375 2 856.575 2 905.250
3 807.400 3 774.025 3 798.025 3 807.125 3 858.650 3 908.500
4 810.275 4 775.925 4 799.925 4 807.750 4 863.475 4 911.750
5* 811.550 A 776.075 A 800.075 5 809.000 5* 864.700 5 915.000
6 801.100 b 777.975 b 801.975 6 809.500 6 854.900 6 918.250
7 802.325 C 780.725 C 804.725 A 806.250 7 857.950 7 921.500
8 808.600 d 781.925 d 805.925 b 807.500 8 861.750 8 924.750
9 810.550 C 809.625 9 863.500 9 928.000
0** 813.800 d 808.625 0** 864.825 0
* Compatible with each of channels 1-4
** Compatible with each of channels 6-9
Highlighted Channels are compatible with each other
Group G
UST10Australia / EU Japan
Group F
Group K
Group A Group B Group C Group D
China / Korea
A
ustralia / France ChinaN. & S. America
Group E
China Thailand / Taiwan
N. & S. America N. & S. America
Group JGroup H Group L
