Shure PG4 - Replacement Parts; Parts Designations; PG4 Model Variation - Table; Antenna Parts Numbers

28
25A1104 (Rev.1)
REPLACEMENT PARTS
PRODUCT CHANGES
PARTS DESIGNATIONS
The following comments apply to the parts list and the schematics:
Resistors: Unless otherwise noted, all resistors are surface-mount with 1/10 W rating and 1% tolerance.
Capacitors: Unless otherwise noted, non-polarized capacitors are surface-mount NPO dielectric types with a 100 V ca-
pacity and a 5% tolerance, and polarized capacitors are tantalum types.
PG4 MODEL VARIATION
ANTENNA PART NUMBERS
COUNTRY
CODE
FREQUENCY
RANGE
COUNTRY
DESIGNATION
PC BOARD
ASSEMBLY
H7 536-548 MHz N. & S. AMERICA 200H710998
K7 590-602 MHz N. & S. AMERICA 200K710998
M7 662-674 MHz N. & S. AMERICA 200M710998
M10 674-686 MHz FRANCE 200M1010998
P11 702-714 MHz CHINA 200P1110998
Q11 740-752 MHz CHINA / KOREA 200Q1110998
R10 800-812 MHz EU 200R1010998
R11 770-782 MHz CHINA 200R1110998
R12 794-806 MHz THAILAND 200R1210998
JB 806-810 MHz JAPAN 200JB10998
T10 854-865 MHz UK 200T1010998
Antenna
Part
Numbers
H7 K7 M7 M10 P11 Q11 R10 R11 R12 JB T10
CH A 44Y8034 44Y8036
CH B 44Z8034 44Z8036
