Battery Installation
ɠ Accessing the Battery
Compartment
Press the side tabs on the bodypack or unscrew the cover on the handheld
as shown to access the battery compartment.
ɡ Installing Batteries AA Batteries: Place batteries (note polarity markings) and AA Adaptor
as shown
Shure SB900 Battery: Place battery as shown (note polarity markings),
remove AA Adaptor from bodypack transmitter, stow AA Adaptor in
door for handheld transmitter
