- 108 -
SVS-560C
General specification
1. Display Screen: 5inch Color LCD with LED backlight
2. Resolution: WVAG (800 X 480 pixels)
3. Power Supply: DC 12V~36V(+-10%) 5W
4. Operating Temperature: -15°C~+50°C
5. Performance Standard: IMO Resolution MSC.112(73)
6. Option: MicroSD, External GPS Antenna
GPS Receiver specification
1. GNSS Receiver Capabilities
GPS L1 C/A code
GLONASS L1OF/
QZSS L1 C/A code
Galileo E1B/E1C/L1
2. Number of Channel: 52 channels
3. Horizontal Positioning Accuracy
Autonomous 2.5m (CEP 50%)
4. Sensitivity
Acquisition -148 dBm
Tracking -165 dBm
Reacquisition -162 dBm
5. Nav Update: 1Hz, 5Hz
6. Support: DGPS, SBAS(EGNOS, WAAS, MASA, GAGAN)
Chartplotter specification
1. Display Method: Mercado Projection
2. Display Mode: True motion / N/S/E/W up / Course up / Head up
3. Latitude Limits: Between 85
°
N to 85
°
S
4. Map Scale: 0.05nm to 1500nm
5. Map Datum: WGS-84
6. Waypoint: 20,000 points
*Total of 16 colors and 16 icons are selectable each point
with name tag (8 alphanumeric characters)
7. Track Point: 50,000 points( 2 types)
8. Route: Max capacity 100 Routes
*20 WPTs per each Route. Each with name tags
(8 alphanumeric characters)
9. Draw Point: 1,000 points
10. Area Name: 1,000 points
11. Chart Data: HY-MAP(Built-in or External)/ C-MAP
12. Output Data: NMEA-0183
13. Input Data: NMEA-0183
14. Alarm: Arrival, Anchor, XTE, Interval timer, User line
