- 33 -
3.6. GPS Status page
①
Receiver status
The current GPS status.
②
Position of SAT.
Position of the satellites.
③
SNB Graph
Showing the WPT and the bearing.
④
Navigation Data
Information of the various data.
* Colors of the GPS status
Black:
Tracked, but no signal
Blue:
Tracked, but not used, Satellite
Green:
Used Satellite
Light Blue:
SBAS Satellite
④
①
②
③
