USING YOUR EXTRACTOR
Induction hob
1. Heating zone selection
2. Power level / Timer adjustment
3. Lock
4. Power ON/OFF
5. Timer
6. Bridge zone selection
Downdraft extractor
7.-8. Extraction speed adjustment
9. Power ON/OFF
10. Delay
1
32
4
5
6
Before Using Your New Induction Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your induction hob.
Using the Touch Controls
• The controls respond to touch so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry and that there are no objects (e.g. a utensil or a cloth) covering them.
rate.
6
USING YOUR INDUCTION HOB
1. Power ON/OFF: Touch this key to turn the extractor on, the digital display will show “0”. Touch this key again to
2. Delay key: When this key is pressed, the extractor will continue to work for 1 minute before turning off.
The delay key will flash to indicate the extractor is in the “delay” mode. To exit this mode, press the key again.
.
3. Extraction speed adjustment keys: Once the appliance has been turned on, touch the + key, the display will show
“1” and the extractor will operate on low speed. Press this key again for medium and high speed operation, the
digital display will show “2” and “3” respectively. When in high or medium speed operation, press – key to reduce
the speed level.
PRODUCT OVERVIEW
Top View
8
10
7
9
Due to power limitation：
2000W zone
2000W zone
1500W zone
1500W zone
The power of the two left heating zones is limited to 3400W. Therefore, simultaneous operation of
both of these zones allows one zone to be set to a maximum level of “9” and the other to a
maximum level of “8”. Same power limitation applies to the right two heating zones.
