I 14
SIBER DF / INSTALLATION MANUAL
Screw the Silentblock Hooks into the desired new position.
2.3
Long Side Short Side
Drill the marked surface and screw the fixing brackets through the oval holes.
Loosen the wing-nuts and leave 1 cm of
space
Place on top of the guide and slide
until it engages with the threaded
rod.
Tighten the wing-nuts
1 cm
3
4 5
6
To Next Page
