Page S.04 (ETHERNET) is dedicated to the status of the connection and of the communication
via Ethernet. It displays the addresses currently used on the controller and the MAC address
associated. In case of working problems, check the information in this page.
The possible statuses related to the communication via Ethernet are:
- On standby: no communication and Ethernet cable disconnected;
- On standby-connecting: no communication and cable connected to the Ethernet network;
- Communicating: communication and cable connected to the Ethernet network.
The addresses displayed are:
- IP: IP address used by the controller;
- RT: gateway address (or router);
- SUBN: subnet mask value;
- DNS: DNS server address.
Note: This page is displayed only if the controller is equipped with the Ethernet optional
module.
Page S.05 (CONTROLLER) is dedicate to ATS115-ATS115
Plus
and contains:
The language currently used by the device. It allows you to select among the ones
installed.
Current date and time in long format (flashing if the clock is not valid).
The measure of the source (power-up battery) voltage of the controller.
The unambiguous serial number of the controller (called ID CODE).
The code of the software currently loaded on the controller.
Digital inputs can be configured as “generic status” using the following functions:
“DIF.3201” and “DIF.3202”: displayed at page S.06.
“DIF.3203” and “DIF.3204”: displayed at page S.07.
“DIF.3205” and “DIF.3206”: displayed at page S.08.
In this way, you can acquire and visualize the statuses that do not strictly depend on the logic
of the controller and that do not refer to warnings or blocks.
The pages are automatically (and individually) hided if there are not inputs configured with the
previous functions.
S.04 ETHERNET |
ETH0: standby-conn.
MAC 00 1B C5 09 CF FE
IP 192.168.150.112
RT 192.168.150.254
SUBN. 255.255.255.0
DNS 192.168.150.220
T 192.168.1.112
To Next Page
