SICK FLPS Series User Manual

Installation
FLPS Multibarrier · Operating Instructions · 8021769/V 1-0/2018-03 · © SICK Engineering GmbH 21
Subject to change without notice
Connections for intrinsically safe supply of the gas flow meter
n.s. negligible small,
∑ The values are valid as the sum for terminals Aux, 1A, 1B, 2A, 2B
Parameter
IIA IIB IIC Unit
Gas flow meter voltage supply (intrinsically safe), terminal -Vout+
U
o
16.5 16.5 16.5 V
I
o
463 463 463 mA
P
o
1.3 1.3 1.3 W
C
o
2.2 2.45 0.415 μF
L
o
0.8 0.4 0.1 mH
L
o
/R
o
148 74.4 18.6 μH/Ω
Current loop intrinsically safe power supply, terminal -Vcl+
U
o
16.5 16.5 16.5 V
I
o
89 89 89 mA
P
o
368 368 368 mW
C
o
9.8 1.9 0.2 μF
L
o
32 16 2.3 mH
Switching inputs FI.O (DI.0), FI.1 (DI.1), DO.2, DO.3 supply (intrinsically safe)
U
o
16.5 16.5 16.5 V
I
o
9.7 9.7 9.7 mA
P
o
40 40 40 mW
C
o
9.8 2.45 0.41 μF
L
o
300 200 100 mH
U
i
16.5 16.5 16.5 V
C
i
000μF
L
i
000mH
Serial interfaces RS485 supply (intrinsically safe), terminals 1A, 1B, 2A, 2B
including auxiliarxy power-
U
o
7.14 7.14 7.14 V
∑I
o
164 164 164 mA
∑P
o
293 293 293 mW
∑C
o
296 196 2.55 μF
∑L
o
52.50.33mH
U
i
7.14 7.14 7.14 V
∑C
i
3.45 3.45 3.45 μF
L
i
n.sn.sn.smH
