SICK IDM1 Series Quick Start

8015904/YIT8/2015-03-02 © SICK AG · Germany All rights reserved - Subject to change without notice
13
15. Serial Interface Control
Command Parameter Selection Option Code
STX/ETX Control Disable STX/ETX transmission ◆
Enable STX/ETX transmission
0
1
Record Suffix
None
CR ◆
LF
CRLF
TAB
SPACE
User define character
0
1
2
3
4
5
6
Preamble None ◆
1-15 characters
FIN
[00-7F], [FIN]
Postamble
None ◆
1-15 characters
FIN
[00-7F], [FIN]
Handshaking Protocol None ◆
RTS/CTS
ACK/ NAK
Xon/Xoff
0
1
2
3
Intermessage Delay
None ◆
1-99 (x5) msec.
FIN
(2 digits)
Intercharacter Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
Interfunction Delay
None ◆
1-99 (x5) msec.
FIN
(2 digits)
Serial Response Time-out
None
200 msec.
500 msec. ◆
800 msec.
1 sec.
2 sec.
3 sec.
4 sec.
5 sec.
8 sec.
10 sec.
15 sec.
0
1
2
3
4
5
6
7
8
9
A
B
NAK Retry Count 3 times ◆
0~255 times
FIN
(3 digits)
Message String Breakdown
Keyboard interface output (PS/2, DOS/V, USB HID)
Preamble Data Length Prefix ID Scanned Data
Suffix ID Postamble Record Suffix
1-15 char. 2-4 digits 1 or 3 char. Variable 1 or 3 char. 1-15 char. 1 char.
Serial interface output (RS-232, USB COM Port Emulation)
STX Preamble Data Length
Prefix ID Scanned Data
Suffix ID Postamble
ETX Record Suffix
1 char. 1-15 char. 2-4 digits 1 or 3 char. Variable 1 or 3 char.
1-15 char. 1 char. 1 char.
