Technical specifications
96 © SICK AG · Germany · All rights reserved · Subject to change without notice 8012471/ZN27/2017-06-09
Operating Instructions
LMS1xx Laser Measurement Sensors
Chapter 10
Serial auxiliary interface
Communication protocol RS-232 (proprietary)
Transmission speed 9.6 kBd 57.6 kBd 115.2 kBd
Serial host interface
Communication protocol RS-232 (proprietary)
Transmission speed (selectable) 9.6 kBd 57.6 kBd 115.2 kBd
Cable length at 38,400 kBd and wire cross-section 0.25 mm²
(approx.
24 AWG)
15 m
Galvanic de-coupling Yes
Wire cross-section of the connecting cable
(American Wire Gauge — AWG)
0.25 mm²
(approx.
24
AWG)
Ethernet 10/100 MBit/s
CAN 20 kBit/s, 500 kBit/s, 1 MBit/s
1) Corresponds to Diamond Grade 3000X™ (approx. 1,250 cd/lx × m²).
2) The time after the first reflected pulse from which measurement can be performed with full accuracy is dependent on the target that
reflected the first reflected pulse.
3) The time after the first reflected pulse from which measurement can be performed with full accuracy is dependent on the target that
reflected the first reflected pulse.
4) Under the following conditions: the cables plugged into the M12 round plug-in connections must be screwed tight. Any electrical
connections that are not being used must be fitted with protective caps or plugs that are screwed tight (as in the delivery condition).
The M8 connection on the front is screwed tight.
5) Without fixing screws and projection of cable glands with system connector mounted.
6) If the switching inputs are used, the mimimum switching voltage is at least DC 11 V
7) If the switching inputs are used, the mimimum switching voltage is at least DC 11 V
Minimum Typical Maximum
Tab. 38: Data sheet LMS1xx/LMC1xx (cont.)
