SICK PowerProx WTT12L-A Series User Manual

1 General safety notes
■
Read the operating instructions before commissioning.
■
Connection, mounting, and configuration may only be performed by trained
specialists.
■
2006/42/EC
NO
SAFETY
Not a safety component in accordance with the EU Machinery Directive.
■
When commissioning, protect the device from moisture and contamination.
■
These operating instructions contain information required during the life cycle of
the sensor.
EN/IEC 60825-1:2014
IEC60825-1:2007
Laser
1
Maximum pulse power < 20 mW
Puls length: 5.3 µs
Wavelength: 940 nm
Complies with 21 CFR 1040.10
and 1040.11 except for deviations
pursuant to Laser Notice No. 50,
dated June 24, 2007
LASER CLASS 1
ATTENTION
WARNING: Interruption, manipulation or incorrect use can lead to hazardous exposure
due to laser radiation.
2 Notes on UL approval
The device must be supplied by a Class 2 source of supply.
UL Environmental Rating: Enclosure type 1
3 Product description
3.1 Intended use
The WTT12L-Axxxx is an opto-electronic photoelectric proximity sensor withanalog dis‐
tance value output (referred to as “sensor” in the following) forthe optical, non-contact
detection of objects. If the product is used for anyother purpose or modified in any way,
any warranty claim against SICK AGshall become void.
1 GENERAL SAFETY NOTES
4
8020879.ZM26 | SICK
Subject to change without notice
