SICK S300 Mini Mounting Instructions

Pin Signal Function
Housing FE/screen Functional earth/screen
1)
For unambiguous identification of the S300 Mini in the EFI system. On the host, apply 0 V DC to pin 1
(H/G). Appl
y 24 V DC to pin 1 (H/G) on the guest.
A
6
5
3
4
1
2
B
1
M5×8
MOUNTING INSTRUCTIONS
8025884/2020-08-31 | SICK M O U N T I N G I N S T R U C T I O N S | S300 Mini
9
Subject to change without notice
