SICK S300

5
4
3
2
1
9
8
7
6
Figure 5: Measurement data output: Female connector, D-Sub, 9-pin
Me
asurement data output: Female connector, D-Sub, 9-pin
PIN Designation Function
1 RxD– RS-422 interface to measurement data output
2 RxD+
3 TxD+
4 TxD–
5 nc Not connected
6
7
8
9
Housing FE Functional earth/shield
A
5
3
2
4
1
B
1
M5×8
MOUNTING INSTRUCTIONS
8025883/2020-08-31 | SICK M O U N T I N G I N S T R U C T I O N S | S300
