Example:
Safe suppression of the background
White background (90 %)
Black object (6 % remission)
Set sensing range x = 500 mm
Needed minimum distance to white
background y = 10 mm
0
10
(0.39)
20
(0.79)
0
Minimum distance in mm (y) between the set sensing
range and white background (90 % remission)
Distance in mm (inch)
Recommended sensing range for
the best performance
30
(1.18)
y
x
800
(31.50)
600
(23.62)
400
(15.75)
200
(7.87)
2
6%/6%
6%/90%
33
6%/6%
6%/90%
6%/6%
6%/90%
1
