NOTE
Operating mode 6 can only be used together with background suppression (LED 1).
NOTE
Setting the operating modes and the associated teach-in procedures is shown in the
following tutorial:
3.4 IO-Link communication interface
The product comes with the IO-Link communication interface.
IO-Link communication is a master-device communication system.
The product can be operated in standard I/O mode (SIO) or IO-Link mode (IOL). All
automation functions and other parameter settings are effective in IO-Link mode and in
standard I/O mode.
The following functions are supported via the standard IO-Link communication inter‐
face:
•
Flexible sensor settings
•
Digital transmission of sensor signals to the IO-Link Master
•
Visualization and configuration of the sensor
•
Diagnostics /condition monitoring
•
Device identification
•
Easy device replacement
•
Events
A detailed description of the configurable functions and associated indices can be
found in the “IO-Link description” technical Information: Technical Information: Photo‐
electric sensors, SICK Smart Sensors / IO-Link.
3.4.1 Documentation and accessories
Accessory components and additional information are available for integrating and
configuring the IO-Link device. You can find documentation and software, accessories
and links using the SICK ProductID, see "Product identification via the SICK product ID",
page 39.
Documentation and software
•
IODD: Device description file
•
IODD overview: List of IODD contents
•
IO-Link description: detailed description of the process data, service data, and
events of the IO-Link device
Technical Information: Photoelectric sensors, SICK Smart Sensors / IO-Link
•
SDD: Graphical user interface
•
Function Block Factory
•
SOPASET: Configuration software
Accessories
•
IO-Link-Master
•
Connecting cables
4 Mounting
Mount the sensorusing a suitable mounting bracket (see the SICK range of accesso‐
ries).
