11 Technical data
11.1 Technical specifications
The “Technical Data” section contains only an extract of the technical data of the sensor.
The complete technical data can be found on the homepage www.sick.com under the part number of the sensor.
Features
Sensing range
WTM4S
Min. sensing range 4mm (MultiMode 1, 3, 4, 5)
0mm (MultiMode 2)
4mm (MultiMode 1 + 6)
Sensing range max. 250mm (MultiMode 1, 3, 4, 5)
250mm (MultiMode 2)
500mm (MultiMode 1 + 6)
Recommended sensing range for the best performance 40mm ... 170mm (MultiMode 1, 3, 4, 5)
40mm ... 140mm (MultiMode 2)
50mm ... 200mm (MultiMode 1 + 6)
Reference object Object with 90% remission factor (complies
with standard white according to DIN5033)
Distance value
MultiMode M
Distance value measuring range 10mm … 250mm
Distance value-resolution 0.1mm
Distance value reproducibility
Distance value – accuracy
Distance value output via IO-Link
Refresh rate of distance value 20ms
Emitted beam
WTM4S
Light sender PinPoint-LED
Type of light Sichtbares Rotlicht
Light spot size / distance 4.0 mm (150 mm)
Communication interface
Table 13: Communication interface
IO-Link
WTM4S
IO-Link 1.1
Data transmission rate COM2
Electrical data
WTM4S
Supply voltage U
B
DC 10 ... 30 V
1)
Ripple ≤ 5 Vpp
Current consumption 25 mA
Protection class III
1)
Limit values
Reverse polarity protected U
B
connections
Residual ripple max. 5V
ss
