SICK WTM4S - Page 97

MultiMode 6
0
Distance in mm (inch)
Dimensions in mm (inch)
5
(0.20)
10
(0.39)
–10
(–0.39)
–5
(–0.20)
0
Recommended sensing range for
the best performance
300
(11.81)
200
(7.87)
100
(3.94)
400
(15.75)
500
(19.69)
600
(23.62)
500
(19.69)
110
(4.33)
10
(0.39)
Figura 18: WTB4SP-xxxxxAxx
MultiMode 2
0
Distance in mm (inch)
Dimensions in mm (inch)
5
(0.20)
10
(0.39)
–10
(–0.39)
–5
(–0.20)
0
Recommended sensing range for
the best performance
150
(5.91)
100
(3.94)
50
(1.97)
200
(7.87)
250
(9.84)
300
(11.81)
10
(0.39)
250
(9.84)
110
(4.33)
Figura 19: WTF4SD
11.4 Estructura de los datos de proceso
WTM4S A00
IO-Link V1.1
Datos de proceso 2bytes
Byte 0: bits 15... 8
Byte 1: bits 7... 0
Bit 0/tipo de datos Q
L1
/booleano
Bit 1/tipo de datos Q
L2
/booleano
Bit 2 ... 15/descripción/tipo de datos Modo 1-6: Current Receiver Level [dígitos]
Modo 7: Valor de distancia [0,1mm]
