AC MUM0040 rev. 11 - 16 -
MR12 - MR12C
- clean the area around the oil ller cap on the winch to
prevent from entering dirt or deposits which could cause
serious damage to the machine
- remove the oil ller cap
- place a container under the drain plug to collect the used oil
- unscrew and remove the drain plug and wait a few minutes
for the tank to drain completely.
- clean the drain plug and the area where it is housed with
a cloth; ghten the plug and make sure to also insert the
washer; ghtly fasten.
- thoroughly clean the surface of the new oil container, the
ller cap and the area surrounding it to prevent dirt or
deposits entering the winch. Failure to comply with these
instrucons may cause serious damage to the machine.
- pour the oil through a clean spout unl the level on the tran-
sparent gauge is reached.
- replace the ller cap.
10.2. CHECKING THE OIL LEVEL
Checking the oil level can be done immediately by checking the tran-
sparent gauge. If the oil level is low, top up using the same type of oil
that is in the winch. To top up, follow the above steps.
The oil level must be checked when the machine has been
o for at least 30 minutes.
WARNING
The used oil must be given to a rm that is authorised to dispose of it.
Do not release into the environment.
① Oil level gauge
1
