Sicor MR12 User Manual

AC MUM0040 rev. 11 - 18 -
MR12 - MR12C
12. ELECTRICAL WIRING DIAGRAM
DELTA CONNECTION
TERMOCONTACTS
Vmax 250 V(AC) 50/60 Hz
Imax 2,0 A cosφ 0,95
THERMISTORS
RESISTANCE
T<150°C ≤ 300 Ohm
T>150°C ≥ 4 KOhm
Do not apply voltages > 2,5 V
to thermistor terminals
STAR CONNECTION
ETI0140_REV01
2W
2V
2U
Y
1W
1V
1U
Y
TH
TH
N
L
BRK-
BRK+
2W1
2V1
2U1
2W2
2V2
2U2
1W1
1V1
1U1
1W2
1V2
1U2
Thermistor
Thermal Contacts
Brake Coil 1
Brake Coil 2
FAN
HIGH
SPEED SUPPLY
VVVF
AC2
LOW
SPEED SUPPLY
THERMISTOR
FAN
SUPPLY
BRAKE
SUPPLY
2W1
2V1
2U1
2W2
2V2
2U2
2W
2V
2U
Y
1W
1V
1U
Y
1W1
1V1
1U1
1W2
1V2
1U2
