Side-Power RC-20E - Table of Contents; Model Range

Installation & User Manual, Radio Remote rev 1_0_4 Page 2
We Sleipner Motor AS declare that this
device complies with health and safety
requirements according to the Directives
EN301 489-3 V1.4.1:2002
EN301 489-1 V1.4.1:2008
IEC 60533:1999
EN300 220-1 V2.3.1:2010
EN300 220-2 V2.3.1:2010
The radio remote control can control a single bow thruster/windlass or a bow and stern thruster/
windlass combined. The receiver can receive the signals of up to four transmitters.
Remote control kit RC-20E consists of:
- Receiver: Part no. RCR-2E
- Transmitter (incl. battery): Part no. RCT-20E
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Remote control kit RC-21E consists of:
- Receiver: Part no. RCR-2E
- Transmitter (incl. battery): Part no. RCT-21E
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Remote control kit RC-22E consists of:
- Receiver: Part no. RCR-2E
- Transmitter (incl. battery): Part no. RCT-22E
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Remote control kit RC-23E consists of:
- Receiver: Part no. RCR-2E
- Transmitter (incl. battery): Part no. RCT-23E
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Additional transmitters can be ordered separately;
The transmitter and the receiver have the same factory preset code so no programming is neces-
sary. The battery is already inserted in the transmitter.
When additional transmitters are to be used, the new transmitter(s) must be paired with the re-
ceiver (please see programming section).
Model range................................................................................................................................ 2
Technical specications .............................................................................................................. 3
Important precautions ................................................................................................................. 3
Receiver installation ................................................................................................................... 4
User precautions ........................................................................................................................ 6
How to use RC20E ...................................................................................................................... 7
How to use RC21E ...................................................................................................................... 8
How to use RC22E ...................................................................................................................... 9
How to use RC23E .................................................................................................................... 10
Transmitter LED operation and alarm indication ....................................................................... 12
Electric diagram ......................................................................................................................... 13
Output signals diagram.............................................................................................................. 14
Programming additional transmitters ......................................................................................... 15
Replacing transmitter battery.................................................................................................... 16
Dimensions .............................................................................................................................. 17
Model range
Contents
