SE80/185T & SE100/185T Ignition Protected thruster assembly 1.0 - 2007
11
SP75Ti / SP95Ti ignition protected thruster assembly
1.2.1 - 2007
"Visual" wiring diagram
A2A1
Fuse
9681245
red
grey
blue
black
grey
blue
brown
red
6 1230i
Electronic
control box
Thermal
switch
Battery
12V
or
24V
Battery
main
switch
M
4
3
2
1
3
red
red
black
7
white
