23
614 6
2 2 019
-
SH 360
Control Panel Installation
EN
Find a suitable location for the control panel where it does not obstruct or is obstructed by other devices. Install the control panel on a at surface where
it is easy to use.
1. Use the supplied cut-out template to mark the area to remove on your control dash.
2. Cut out the area per template for the control panel. (NB: If the front surface around your cut out is jagged or chipped, use a sealant
to assist the gasket.)
3. Place the gasket to the back face of the panel
4. Plug cables into the connectors at the rear of the control panel.
5. Insert the control panel in place and fasten screws.
6. Insert the control panels covering caps.
MC_0042
! Please refer to the graphic for special considerations relating to your model !
MG_0063
GASKET
4x SCREWS
58 mm
67 mm
125 mm
116 mm
132.7 mm
75.7 mm
Ø 4.5 mm Ø 4.5 mm
Ø 4.5 mm Ø 4.5 mm
(S-link)
External alarm buzzer
12V / 24V DC - max 0,5A
External alarm / buzzer connection
Supply
+ 12V / 24V DC
-
+
Ø 4.5 mm
Re
a
r
s
i
d
e
o
f
p
a
n
e
l
Internal
fuse / relay
MC_0049
Checklist for Hydraulic Thrusters
EN
�.......... Propeller is fastened correctly to the shaft.
�.......... Propeller turns freely in tunnel.
�.......... Lower-unit is lled with gearoil.
�.......... Oil-drain screw is tightened and the copper seal is present.
�.......... The anode holding screw is tightened well with thread glue.
�.......... Anti-fouling have been applied to the gearhouse and propeller but NOT on the anode or the
gearhouse lid where the propeller is fastened.
�.......... Oil tank is tted above the waterline as required and lled with gearoil.
�.......... Correct drive direction as per controlpanel.
�.......... The bolts holding the gearhouse and motorbracket together are tightened correctly.
�.......... The bolts holding the motor to its bracket are tightened correctly.
The thruster has been installed as per the instructions in this manual and all points in checklist above have been controlled.
Signed: .........................................................................................
Date: .............................................................................................
Extra pre-delivery tests by installer / yard who does not use other quality control systems !
Thruster type: ................................................................................................................................................................................................
Serial number:...............................................................................................................................................................................................
Date of delivery:.............................................................................................................................................................................................
Correct drive direction as per controlpanel: ..................................................................................................................................................
The compartment for the thruster has been isolated from general bilge water and has no obvious or suspected risks for ooding:
......................................................................................................................................................................................................................
......................................................................................................................................................................................................................
......................................................................................................................................................................................................................
Other comments by installer: ........................................................................................................................................................................
.......................................................................................................................................................................................................................
