Side-Power SH-360 User Manual

5
614 6
2 2 019
-
SH 360
MC_0056
Technical Specifi cations
EN
Motor: Hydraulic type (speci cations above).
Gearhouse: Seawater resistant bronze. Ballbearing at propeller shaft and a combination of ball bearing and slide bearing at driveshaft.
Gears: Hardened precision gears
Lubrication: Oil bath from tank (gear oil EP 90)
Bearings: Angular contact ball bearing at propellershaft and combination of ball bearing and needle bearing at driveshaft.
Motor bracket: Seawater resistant aluminium, galvanically insulated from the motor.
Tunnel: Cross spun with rowing G.R.P tunnel
Steel & aluminium tunnels available at request.
Propeller: SH 100/ SH 160/ SH 240/ SH 320/ SH 360: 5-blade skewback “Q-prop” propeller,  breglass reinforced composite.
SH 420/ SH 550 Symmetrical 4 blade kaplan propeller,  breglass reinforced composite.
Safety: Flexible coupling between hydraulic-motor and driveshaft protects gearsystem if propeller jams.
MG_0078
TL
WD
ID
T
Propeller position will vary
on the model
The gear leg must never extend
out of the tunnel
Tunnel centre line
Twin Propeller
H
WL
MC_0214
Thruster Measurements
EN
Measurement
code
Measurement description
mm inch
ID Internal tunnel diameter 300 11.81
H Motor Height 356 14.02
W Width 258 10.16
L Length 258 10.16
WD Water Depth 450 17.72
TL Minimum tunnel length 370 14.57
TL (recommended) Recommended tunnel length 550 21.65
T (min) Minimum tunnel wall thickness 10 0.39
T (max) Maximum tunnel wall thickness
*360
MC_0215
Thruster Specifi cations
EN
description * 360
light duty thrust up to (kg * lbs) 360kg * 795lbs
Heavy duty thrust up to (kg * lbs) 270kg * 594lbs
Typical Boat Size (m * ft) 18m - 33m * 59ft - 108ft
Propulsion System Twin Counter Rotating
Power (kw * Hp) 27kw * 37hp
Weight (kg * lbs) 26 kg * 57.32 lbs
Lubrication Sealed

Side-Power SH-360 Specifications

General

Brand	Side-Power
Model	SH-360
Category	Marine Equipment
Language	English
