Montering av elektromotor
N
Fitting the electromotor
GB
Bolt tightening force (4x):
651POEIW
1. Remove the 4 bolts in the motor bracket.
2. Place the motor gently on the motor bracket. Be careful, the motor is
heavy! Ensure that key on axle and keyway in one-piece coupling are
aligned. Ensure that you are placing the motor so that the cable termi-
nals on it are available for electric installation later.
3. Fasten the motor to the bracket with the 4 bolts and tighten them.
4. Check if the springs for the brushes sit correctly on the brushes
(see through the metal web around the top of the electromotor).
5. Check the drive system by turning the propeller, it will be a little
hard to turn (because of the gear reduction and the motor), but you
should easily be able to turn it by hand.
NB! Paint the gearhouse and propeller with antifouling for propel-
lers to prevent growth of barnacles or similar which would reduce the
performance dramatically. Do not paint the propeller shaft, the zincan-
odes or the end face of the gearhouse.
NB! Do not run the thruster for more than very short bursts without
being in the water.
NB! If the boat is still being built when the electromotor is installed, it
must be covered up to avoid dust from the building going into the mo-
tor and the solenoids. This cover must be removed before the thruster
is being used.
 )MHUQGHEROWHQHLPRWRUEUDNHWWHQ
2. Plasser motoren på braketten. Plasser motoren slik at releene er
WLOJMHQJHOLJHIRUWLONREOLQJVHQHUH7DKHQV\QWLODWPRWRUHQHUWXQJQnU
GHQEUHVRJKnQGWHUHV
 6MHNNDWNLOHVSRULJXPPLNREOLQJRJNLOHSnDNVHOHUSnOLQMH
 )HVWPRWRUHQWLOEUDNHWWHQPHGGH¿UHEROWHQH
 6MHNNDWE¡UVWHIMUHQHVLWWHUNRUUHNWSnE¡UVWHQHJM¡UHVYHGnVH
JMHQQRPJLWWHUHWSnVLGHQDYPRWRUHQ
 7HVWLQVWDOODVMRQHQYHGnGUHLHSnSURSHOOHQ'HWYLOYUHPRWVWDQG
SJDJLUXWYHNVOLQJRJPRWRUPHQGHWVNDOHQNHOWODVHJJM¡UHnGUHLH
propellen for hånd.
NB ! Påfør bunnstoff på girhus og propell for å unngå vekst som kan virke
sterkt hemmende på thrusterens effekt. Sinkanoder propellaksling og
tetninger skal ikke stoffes.
NB !7KUXVWHUHQPnNXQNM¡UHVLPHJHWNRUWHSHULRGHUQnUGHQOLJJHUSn
land.
NB ! Hvis båten fortsatt er under bygging når thrusteren blir montert må
motoren dekkes til for å unngå at støv og lignende trenger inn i girhus og
HOHNWURPRWRU'HNNHWPnIMHUQHVI¡UPRWRUHQWDVLEUXN
