c. Caution: DO NOT connect red and black leads directly to motor
control module or damage to wireless receiver module will
occur.
d. Connect “24v positive” and “Common Ground” terminals on the battery
to “battery neg” and “battery pos” on the motor control module.
e. Connect the green and blue leads from the 4 pin motor control cable to
“switch 1” and “switch 2” on the motor control module.
f. Plug the 4 pin motor control cable into the black wireless receiver control
module.
NOTE: The joystick and wireless key fob are preprogrammed for operation.
No pairing or programming is required.
