SIDESHIFT INSTALLATION GUIDE V2.7
5
Center Bolt
Attaches clamp strap to thruster
Lock Nut (1)
Locks center bolt in place
Threaded hull insert and
bolts (2)
Secures clamp strap assembly to
hull.
Hull insert epoxy kit
Cements threaded hull inserts in
place
