09.02 Connection
Siemens AG 6SE7087-6AK85-1AA0
3-37
Rectifier/Regenerating Unit Operating instructions
V11
V24
V13
V26
V14
V21
V16
V23
V15
V22
V12
V25
Level BLevel A
Figure 3.26 Arrangement of the thyristor blocks, view from right-hand side of unit, Size K (see dimension drawing in Section 2.4)
