Parameter List 09.02
5-36 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
PNU
*
: Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
5.14 Modulator
P773 Deadband Convert
The reversing threshold of the auto-reversing module (in rectifier direction)
If the (signed) setpoint of the DC link current (output of the DC link voltage
controller on the output side of the limiting module) exceeds
the value of +
0.05% set with this parameter, the firing pulses of the rectifier bridge are
enabled. These pulses are inhibited if the setpoint of the DC link current
drops below the value set here.
RDS parameter
PNU=305Hex; Type=O2; Scaling: 1Hex
=
∧
0.01 %
0.01 to 100.00
[%]
4
0.01
3/ BR
3/ BR
P774
**
Deadband Invert
The reversing threshold of the auto-reversing module (in regenerating
direction)
If the (signed) setpoint of the DC link current (output of the DC link voltage
controller on the output side of the limiting module) exceeds
the value of -
0.05% set with this parameter, the firing pulses of the rectifier bridge are
enabled. These pulses are inhibited if the setpoint of the DC link current
drops below the value set here..
RDS parameter
PNU=306Hex; Type=O2; Scaling: 1Hex
=
∧
0.01
-100.00 to -0.01
[%]
4
-3.00
3/ BR
3/ BR
P775 Min Gating Angle
Alpha G limit (rectifier stability limit)
RDS parameter
PNU=307Hex; Type=O2; Scaling: 1Hex
=
∧
1 °el
0 to 120
[°el]
4
0
3/ BR
3/ BR
P776 Max Gating Angle
Alpha W limit (inverter stability limit)
RDS parameter
PNU=308Hex; Type=O2; Scaling: 1Hex
=
∧
1 °el
120 to 165
[°el]
4
150
3/ BR
3/ B
P777 Max Gating Angle Ramp
Transition ramp of the alpha W limit from pulsating to continuous DC (for
currents < pulsating threshold, the control angle is limited to 165°, for
currents > (pulsating threshold+P777) to P776 with linear interpolation
inbetween)
RDS parameter
PNU=309Hex; Type=O2; Scaling: 1Hex
=
∧
1 %
0.00 to 100.00
[%] of P075
4
20.00
3/ BR
3/ BR
