Connection 09.02
3-10 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating instructions
Size K:
Rated short-time withstand current: I
cw
= 69,86 kA / 1s or I
cw
= 220 kA / 0.1s
Rated surge withstand current: I
pk
=85 kA
The power rails must be mechanically buffered to absorb the short-circuit forces directly in front of their entry
point into the unit.
NOTE
Because the quick-tripping semiconductor fuses are external on devices up to and incl. size E, no data is
given about short-circuit capability for these devices.
Unit Order No. Rated input Regen.- Commutating reactor
Type Voltage / Frequency Rated
voltage curr. current current
6SE70 (V) (A) (A) (V / Hz) (V / Hz) (A)
22-1EC85-1AA0 380 to 480 18 20 4EP3700-7UK 400 / 50 460 / 60 18
24-1EC85-1AA0 380 to 480 36 40 4EP3900-5UK 400 / 50 460 / 60 35,5
28-6EC85-1AA0 380 to 480 74 82 4EU2451-4UA00 400 / 50 460 / 60 80
31-7EE85-1AA0 380 to 480 149 165 4EU2751-1UB00 400 / 50 460 / 60 160
32-2EE85-1AA0 380 to 480 192 212 4EU2751-2UB00 400 / 50 460 / 60 200
33-1EE85-1AA0 380 to 480 269 297 4EU3051-7UA00 400 / 50 460 / 60 280
33-8EE85-1AA0 380 to 480 326 360 4EU3051-8UA00 400 / 50 460 / 60 355
34-6EE85-1AA0 380 to 480 403 444 4EU3651-3UB00 400 / 50 460 / 60 400
36-1EE85-1AA0 380 to 480 526 581 4EU3651-4UB00 400 / 50 460 / 60 560
38-2EH85-1AA0 380 to 480 710 784 4EU3951-6UA00 400 / 50 460 / 60 710
41-0EH85-1AA0 380 to 480 888 980 4EU3951-1UB00 400 / 50 460 / 60 910
41-3EK85-1AA0 380 to 480 1156 1276 4EU4351-3UA00 400 / 50 460 / 60 1120
41-3EK85-1AD0 380 to 480 1156 1276 4EU4351-3UA00 400 / 50 460 / 60 1120
41-8EK85-1AA0 380 to 480 1542 1702 4EU4351-7UA00 400 / 50 460 / 60 1600
41-8EK85-1AD0 380 to 480 1542 1702 4EU4351-7UA00 400 / 50 460 / 60 1600
22-7FC85-1AA0 500 to 600 24 26 4EP3800-8UK 500 / 50 22,4
24-1FC85-1AA0 500 to 600 36 40 4EP4001-0UK 500 / 50 35,5
27-2FC85-1AA0 500 to 600 62 69 4EU2451-5UA00 500 / 50 63
28-8FC85-1AA0 500 to 600 82 90 4EU2551-1UB00 500 / 50 80
31-5FE85-1AA0 500 to 600 131 145 4EU2751-3UB00 500 / 50 140
32-4FE85-1AA0 500 to 600 203 224 4EU3051-0UB00 500 / 50 200
32-7FE85-1AA0 500 to 600 233 257 4EU3051-1UB00 500 / 50 250
33-5FE85-1AA0 500 to 600 307 339 4EU3651-5UB00 500 / 50 315
34-2FE85-1AA0 500 to 600 366 404 4EU3651-6UB00 500 / 50 400
35-4FE85-1AA0 500 to 600 465 514 4EU3651-7UB00 500 / 50 500
37-7FH85-1AA0 500 to 600 671 741 4EU3951-7UA00 500 / 50 710
41-0FH85-1AA0 500 to 600 888 980 4EU4351-5UA00 500 / 50 910
41-3FK85-1AA0 500 to 600 1119 1235 4EU4551-1UA00 500 / 50 1120
